Bar Channels
| Est. Weight, Lbs. | Est. Weight, Lbs. | ||||||
|---|---|---|---|---|---|---|---|
| Size In Inches
A B C |
Per Foot | 20-Ft. Length | Size In Inches
A B C |
Per Foot | 20-Ft. Length | ||
| 3/4 x 5/16 x 1/8 | .50 | 10.00 | 1-1/2 X 9/16 X 3/16 | 1.44 | 28.80 | ||
| 3/4 x 3/8 x 1/8 | .56 | 11.20 | 1-1/2 X 3/4 X 1/8 | 1.17 | 23.40 | ||
| 1-1/2 X 1/2 X 3/16 | 2.65 | 53.00 | |||||
| 7/8 x 3/8 x 1/8 | .61 | 12.20 | |||||
| 7/8 2 7/16 x 1/8 | .69 | 13.80 | 1-3/4 X 1/2 X 3/16 | 1.55 | 31.00 | ||
| 1 x 1/2 x 1/8 | .84 | 16.80 | 2 x 1/2 x 1/8 | 1.43 | 28.60 | ||
| 2 x 9/16 x 3/16 | 1.86 | 37.20 | |||||
| 1-1/8 x 9/16 x 3/16 | 1.16 | 23.20 | 2 x 5/8 x 1/4 | 2.28 | 45.60 | ||
| 2 x 1 x 1/8 | 1.59 | 31.80 | |||||
| 1-1/4 x 1/2 x 1/8 | 1.01 | 20.20 | 2 x 1 x 3/16 | 2.32 | 46.40 | ||
| 1-1/2 x 1/2 x 1/8 | 1.12 | 22.40 | 2-1/2 x 5/8 x 3/16 | 2.27 | 45.40 | ||
